Mountain Code 1200

Mountain Code 1200

€7,490.00

Test Customize

History

New model of electric mountain bike. Taking the Mountain Wolf model as a starting point but customizing design details of the initial model to achieve this Mountain Code 1200 model.

Frame

The Code 1200 model maintains the characteristic carbon fiber frame like the rest of Bewatt. On this occasion, the paint used was a combination of grays: matte gray, gloss gray and gloss carbon, resulting in this original painting.

POWER TRAIN

It maintains the Bafang M560 motor characteristic of our electric mountain bikes as well as the self-made 1200 Wh battery and the latest generation high discharge cells.

PARTNERS

They have the best components on the market. On this occasion, we have used different components from those used in our electric mountain bike models: FOX shock absorbers and MAVIC rims. Michelin E-Wild tires with X-Gun technology and Bafang engine remain.

Image alt
Image alt
Image alt
Image alt
Image alt

CODE 1200 SPECIFICATIONS

- Download user manual

Frame: made of carbon fiber

Complete Toray

-

Motor: Bafang M560 with rated power of 250W

120Nm torque (limited to 25km/h)

-

Battery: Lithium-ion 52v. In-house manufacturing

High discharge cells with a capacity of 1200W/h

-

Shock absorber: Fox

Float Performance 210x55

Fork: Fox

Float Performance 29'' 160mm

-

Handlebar: Shimano PRO Koryak de 35mm

Saddle: ERGON

Postpost: telescopic Crank Brothers

Anchors: titanium screws.

-

Discs: Galfer 203mm and 2mm thick specific e-bikes

Brakes: Shimano SLX 4 pistons

Rims: Mavic E-Deemax 30

Front tire: Michelín E-Wild 29x2.60. Tubeless Ready

Rear tire: Michelín E-Wild 29x2.60. Tubeless Ready

-

Change: Cues 11V.

Crank: Bafang

Cassete: Cues 11V 11/50.

String: Box.

Pedals: Shimano GR400.

Plate: Bafang 38 T aluminum.

-

Display: EPAC with 5 levels of assistance

App: available for iOS and Android.

-

GEOMETRY

SIZES

S-M M-L L-XL
A 110mm. 120mm. 130mm.
B 55,6mm. 55,6mm. 55,6mm.
C 622,8mm. 646,3mm. 674mm.
D 420mm. 446mm. 470mm.
E 623mm. 632mm. 641mm.
F 510mm. 510mm. 510mm.
G 710mm. 710mm. 710mm.
H 1242,3mm. 1266,3mm. 1294,4mm.
I 410mm. 451mm. 510mm.
J 66º 66º 66º
K 72,5º 72,5º 72,5º
L 290mm. 290mm. 290mm.
